AtlasIED VP60R
Vandal Proof Recessed Circular 8" Baffle
Part #: VP60R
Satisfaction Guaranteed!
MSRP: $178.99
Our Price:
$145.99
Top VP60R Specifications
- Depth 1"
- Diameter 12 3/4"
- Shipping Weight 3.13 lbs
- UL Listed/Standard 1480
"Very nice folks to work with. Quick and good information"
-Jeff A.
-Jeff A.
Contact a product specialist!
Proudly supporting our customers since 2008
Description
VP60RRecessed Circular Vandal Proof Baffle For 8" Loudspeaker by Atlas Sound . This Reinforced, protective baffle assembly provides tamper proof recessed installation of a standard 8" cone loudspeaker or an APF Series re-entrant horn. Horn installation requires adapter plate Model FAMT-6.
Trim ring is cast from aluminum alloy with a tensile strength of 44,000 P.S.I. and features a 3/4" shielding collar to protect the loudspeaker from bashing. The loudspeaker securely mounts to welded studs behind a perforated 22-gauge CRS plate which is then protected by a stainless steel-woven wire-mesh screen positioned 3/8" in front of the plate for direct impact protection. The mesh screen is reinforced by a thick bead of sealant on the inside to protect it against tearing or bending. Rugged unit installs via tamperproof heat-treated alloy screws (special wrench supplied) to specified enclosures. Mounting holes are countersunk for added security. Finish is satin aluminum with an acrylic coating.Reviews
