Avenview SW-HDM2-T4K-4X1
4X1 4K60 HDMI Switcher - HDR, IR, RS232, Telnet

Description

The Avenview SW-HDM2-T4K-4X1 4x1 HDMI 4K@60 Switcher allows the transmission of video and multi-channel digital audio at 4K resolution. It allows the transmission of 18Gbps HDMI signal from any of its four HDMI 2.0 source inputs to one HDMI 2.0 with HDCP 2.2 support connected display. With supports 4K2K@60, 48-bit Deep Color, HDR (High Dynamic Range) audio and other features defined by HDMI 2.0 specifications. This device can be operated and controlled easily through front panel buttons, IR remote control, RS-232,
Telnet or Web GUI controls.

Features:

• HDMI 2.0 (with HDR and 4K@60/UHD supported) and HDCP 2.2 compliant;
• Select any one of four HDMI 2.0 sources and display on a HDTV display with fast switching between   sources;
• Full HD Up to 1080p/60 up to 75ft
• Supports HD resolutions up to UHD (3840x2160@24/25/30/50/60 & 4K (4096x2160 @24/25/30/50/60Hz)
• Supports HDR (10 bit 4:2:0)
• Supports HDMI 2.0 data rate from 18Gbps and 'Deep Color' up to 1080p/48-bit
• Supports selection of Standard (Fixed) or TV (Downstream) EDID settings Supports Audio pass-through of High-definition Audio formats PCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
• Supports IR Remote, Telnet, Web GUI control and RS-232

Specifications

• Weight: 4 lbs
• Warranty: 3 Years

Downloads

• Avenview SW-HDM2-T4K-4X1 Specifications (PDF)
• Avenview SW-HDM2-T4K-4X1 Manual (PDF)
