AC-MXNET-10G-TCVR-TAA
TAA - MXnet 10G SDVoE Transceiver
Description
Audio, Video and Control signals reside on autonomously isolated layers within the SDVoE platform, each independently routable for unparalleled flexibility with flawless distribution over a 10GbE copper, fiber, or hybrid-blended network. A built-in, segregated, 1GbE Ethernet w/PoE full gigabit sub-network channel is reserved for high-speed local network connections. When selected for transmitter mode, an AC-MXNET-10G-TCVR sends content from a connected source, via multicasting, to individual or multiple endpoints on the network. In contrast, traditional A/V distribution layouts such as HDBaseT and HDMI anchor a matrix switcher, forcing source localization into the rack environment. Presently, a physical HDMI matrix in a low distance application (one-on-one, point-to-point connections with displays, via NextGen Active Optical HDMI cables) will provide the best video performance for all possible sources, such as 4K/120fps game consoles. With commercial applications such as those industrial or perhaps campus-related, untethered sources injected into a network by an AC-MXNET-10G-TCVR from decentralized locations represents the ultimate in system design freedom and deployment ease. Sources may be set for their highest capabilities (up to 4K/60fps) and the MXnet ecosystem diligently handles all details. Configured for decoder mode, an AC-MXNET-10G-TCVR transforms into a technical tour de force in every conceivable way. Connected to a display, AC-MXNET-10G-TCVR memorizes the displays EDID while automatically adjusting colorspace (colorspace cross-conversion from RGB to YUV when necessary) for all source devices, computers, or streamed video. Any version of HDR metadata is passed-through to HDR-capable displays, while being blocked automatically from SDR displays. Onboard scaling for no-wait, rapid switching also provides MultiView compositing, available on any display type. Video wall arrays are easily configured using built-in, advanced software bezel correction. The MXnet 10G ecosystem supports concurrent system matrixing, MultiView, and Video Wall operation, while independently routing audio, video, control or USB 2.0 signals. Twisted-pair copper, fiber, and hybrid system connectivity is supported, whether the device is commissioned as encoder or decoder. MXnet 10G Mentor access, via the AC- MXNET-10G-CBOX, enables rapid API system configuration changes, with the front-facing OLED display providing eye-glance quick system monitoring.
