KanexPro EXT-PROMATRIXUSB
KanexPro SDVoE powered Modular Matrix Transceiver with USB Extender
Part #: EXT-PROMATRIXUSB
Satisfaction Guaranteed!
Our Price:
$2,309.95
Top EXT-PROMATRIXUSB Specifications
- HDMI 2.0 and DVI 1.0 compatible
- HDCP 2.2 and HDCP 1.x compliant
- Can be configured to function as either a Transmitter or a Receiver
- 1 HDMI input
"Online ordering was very easy and the automated emails kept me up to date on status of the order until delivery"
Contact a product specialist!
Proudly supporting our customers since 2008
Description
Next Gen Modular Matrix System
Specifications
- 1 HDMI output (Functions as local monitor output in Transmitter Mode)
- 1 analog stereo jack (Functions as an input in Transmitter Mode and an output in Receiver Mode)
- 2 USB 2.0 (TypeA) ports and 1 USB 2.0 (MiniB) port
- IP switchable with minimum latency (Requires EXT-PROCTRL)
- Ultra-light compression, lossless for most content
- Extension up to 100m in point-to-point mode (w/ Cat.6A cable)
- Independent breakaway A/V matrix switching (Requires EXT-PROCTRL)
- Video wall generation (Requires
- EXT-PROCTRL)
- Multi-view compositing (Requires
- EXT-PROCTRL)
- Supports pass-through of 10/12-bit HDR sources (Point-to-Point and Genlock mode only)
- Supports pass-through of audio formats including LPCM 2.0/5.1/7.1, Bitstream and HD Bitstream from HDMI sources
- Analog stereo audio extension, insertion and extraction (Requires
- EXT-PROCTRL)
- Bidirectional LAN, IR and RS-232 extension
- Unit can be powered directly by PoE when connected to a 10 Gigabit Ethernet (10GbE) switch that provides PoE (802.3af)
- Signal transmission interfaces with 10-Gigabit Ethernet switches via a single Cat.6A cable
- Basic configuration via front panel buttons with an On-Screen Display (OSD)
- Supports the use of an external control center or control software to provide expanded functionality (Contact your authorized dealer for more information)
