Kramer AV KDock-4
USB C Hub Multiport Adapter with HDMI, VGA, Ethernet, DisplayPort

Description

The Kramer KDock-4 is a USB-C hub multiport adapter specially designed to support mobile devices and is an ideal accessory for MacBook, laptops equipped with USB Type-C, smartphones, and tablets. KDock-4 enables you to connect your USB-C device to HDMI, DisplayPort, and VGA video outputs, 2 USB 3.0 ports, 1 USB 2.0 ports, an Ethernet port, SD and micoSD card port and USB-C charging pass-through.

Note: Video output for smartphones is supported only for smartphones that support DisplayPort Alt mode through USB−C.

Specifications

• Ethernet port
• USB C charging pass through
• SD and MicroSD ports
• Inputs: 1 USB: On a USB Type C male connector
• Outputs: 1 HDMI: On a female HDMI connector, 1 DisplayPort: On a female DisplayPort connector, 1 VGA: On a female 15 pin HD connector
• Ports: 2 USB 3.0: On female USB type A connectors, 1 USB 2.0: On female USB type A connectors, 1 Ethernet: On an RJ 45 connector, SD: On an SD card port, 1 Unbalanced Stereo: On a 3.5mm mini jack, SD: On a microSD port, 1 USB: On a female USB type C connector for charging
• Max Resolution (HDMI/DP): 3840x2160P@30Hz (with one display connected)
• Max Resolution (HDMI/DP): 1920x1080P@60Hz (with two displays connected)
• Max Resolution (HDMI/DP): 1920x1080P@60Hz (with three displays connected)
• Max Resolution (VGA): 1920x1080P@60Hz (with one or two displays connected)
• Max Resolution (VGA): 1280x720P@60Hz (with three displays connected)
• Max Data Rate (HDMI/DP output): 10.2Gbps (3.4Gbps per graphic channel)
• Multiple Video Output Support: Via MST (Multi Stream Transport) technology
• Content Protection (HDMI output): HDCP 1.4
• Max Data Rate: 1000M (Gigabit)/100M/10M
• Includes: Wake on LAN (WoL), single Mac address, PXE boot

Downloads

• Kramer AV KDock-4 Specifications (PDF)
• Kramer AV KDock-4 Manual (PDF)
• Kramer AV KDock Comparison Chart (PDF)
