Kramer AV VP-424C
4K HDR ProScale Digital Scaler/Switcher - HDMI and USB-C Inputs

Description

The Kramer Electronics VP-424C is a high performance 4K digital scaler and auto switcher for HDMI and USB type-C signals. The unit up or down scales the selected video signal to resolutions up to 4K@60Hz (4:4:4) at a maximum data rate of 18Gbps (6Gbps per graphic channel). The user selects the HDMI or USB type-C input and the scaled output is sent to the HDMI output.

Primary Features:

• High Performance Professional Scaler - Up–scales or down–scales HDMI, USB type–C and VGA signals to any resolution up to 4K@60 (4:4:4). The scaler supports HDR10, HDMI 2.0 and HDCP 2.2/1.4, and features Input Auto–Switching, Constant Sync on the output even if the input video signal is lost or interrupted, and a built–in ProcAmp for convenient signal adjustment.

• Fast, Smooth Manual and Auto Switching Between Sources - Select the HDMI or USB Type–C input, or, if no input is selected, the active source is automatically selected.

• EDID Handling - Reading and storage of the video acceptor's EDID.

• Convenient Control - Control the unit using an OSD (On–Screen Display) via front panel buttons and input selector, video freeze and resolution reset front panel buttons. Additionally, connect to the contact closure connector for remote switching of sources. All settings are saved in non–volatile memory.

• User Friendly Operation - LED indicator for each input and for power status. Local firmware upgrade via the USB type–A port ensures lasting, field–proven deployment.

• Easy Installation - Compact MegaTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.

Typical Applications

VP-424C is an ideal solution for the following typical applications:

• Projection systems in conference rooms, boardrooms, hotels and churches.
• Home theater up–scaling.

Specifications

• Inputs: HDMI, USB-C
• Outputs: HDMI
• Content Protection: HDCP 2.2 & 1.4
• Additional Ports: Contact Closure Switches On a 3 pin terminal block, USB-A (Firmware Upgrades)
• Control: Input selection and resolution reset front panel buttons, OSD menu
• Power: 5V DC
• Dimensions: 7.38" x 4.53" x 1"
• Weight: 1.2 lbs
• Included Accessories: Power adapter, bracket set, rubber feet
• Warranty: 7 Years

Downloads

• Kramer AV VP-424C Specifications (PDF)
• Kramer VP-424C Quick Start Guide (PDF)
