Middle Atlantic
SNE24D-4236-P1
24"W,42SP,36"D CONFIG D,F/R PASSIVE ENCL,BK

Description

leveling feet The SNE Series Digital is configured for digital (IP based) security systems consisting of high-density cabling, network equipment, and servers. Optional Tool-Free Lever Lock&trade system accommodates small devices including encoders, power supplies, and Access Control Systems. Fully configured Security Network Enclosure with passive ventilation for data centers o 70% open area vented front door o Pair of split flush mount locking side panels o 2 pair of adjustable cage-nut rackrail (including 6mm hardware) o Lever Lock&trade compatible (accepts all Lever Lock&trade vertical 21" accessories) o 24" width o 36" overall depth o 42 rackspace o 100 6mm cage-nuts/rack screws included SNE Series Digital with passive cooling (front to rear) 70% open area split rear door Solid top with brush cable pass-through Lever Lock&trade compatible (accepts all 21" vertical accessories). UL/ETL listed and seismic certified. Configured for passive front-to-back cooling. Includes 70% open front door and 70% open area split rear door. Includes solid top with brush cable pass-through. Includes 2 pair of adjustable cage-nut rackrail. Includes 100 6mm cage nuts and rack screws. Includes 4 leveling feet. Includes 4 casters.

Specifications

• Application/Usage: Video Encoder
• Application/Usage: Power Module
• Casters
• Adjustable Rear Rail
• Vented
• Lockable Side Panel
• Leveling Feet
• Form Factor: Floor Standing
• Product Color: Black Powder Coat
• Product Material: Steel
• Maximum Weight Capacity: 12000 lb
• Height: 79.5"
• Width: 24"
• Depth: 36"
• Rack Height: 42U
