PureLink VIP-100H II Rx
HDMI over IP Receiver (Decoder) with PoE - Full HD

Description

The PureLink VIP-100H II HDMI over IP distribution system provides video, audio, RS-232, and IR extension, distribution and matrix switching capabilities. Transmitter (encoder) and receiver (decoder) modules can be connected together for point-to-point extension over distances up to 394 ft. (120 m), as well as a point-to-many, many to point, and matrix connections providing up to a 64×190 matrix switching system, or even a 64 x 65K system based on Class B networks.

Key Features

• Support resolutions up to Full HD/1080p
• LED channel display
• Front panel channel plus/minus buttons
• IR remote control for familiar channel selection
• PoE (Power over Ethernet) – power encoders/decoders from 802.3af PoE network switches
• RS232 & IR extension/distribution
• HDMI Loop out on Transmitter
• HDCP compliant

Point-to-point or matrix system:

• up to 64 x 190 matrix (hardware) on Class C networks
• up to 64x 65K on Class B networks

Specifications

• Supported Distance: 390'
• Supported Resolutions: 1080p / 1920x1080
• Compliance: HDCP 1.3
• RS-232: Phoenix 3 pin
• IR Extension: 1/8"
• Power Supply: 120-240 VAC to 5 VDC, 1A
• Power over Ethernet: 802.3af
• Dimensions: 1.1" x 4.7" x 3.1
• Weight: 0.61 lbs
• Warranty: Limited 3 Years

Downloads

• PureLink VIP-100H II Rx Specifications (PDF)
